Building Event-Driven Software While Keeping Your Sanity

5 min read Michael Carroll on Oct 1, 2023
Event Driven Software.png

Event-driven architecture (EDA) is rapidly becoming a cornerstone of the application programming interface (API) and general app development process. As it becomes more widely adopted, developers must understand how to integrate this paradigm while avoiding common implementation pitfalls.

This article will cover what you need to know about EDA and our best tips for integrating it successfully into your workflow.

What is event-driven architecture?

EDA is a design pattern with loosely coupled components emphasizing the use of events to trigger and communicate between different system components. When an event occurs, it triggers a response from one or more components in the system, which take action based on the notification.

Unlike traditional sequential programming — which follows a predetermined set of instructions in a predefined order — event-driven software does not have a predefined flow of execution. Instead, events drive the program flow. This enables more responsive and efficient programming because the program only needs to execute code in response to events rather than constantly polling for changes or performing unnecessary computations.

What is an event?

Everything that happens depends on an event, a significant change, or an action within a system or application. Events are often represented as objects or messages containing information about the event, such as its type, time of occurrence, and associated data or parameters.

Types of events include:

  • User events: mouse clicks or keyboard inputs

  • System events: system start-up or shutdown

  • Network events: incoming data packets

  • Custom events: actions specific to the target application

Events provide a flexible and scalable way to handle multiple actions simultaneously and respond quickly to changes in the system or environment.

For example, a user clicking a button in a game triggers an event handled by the program immediately, rather than waiting for the program to complete other tasks before responding to the user's action. In another example, an IoT sensor detects a temperature change and generates an event that notifies the system administrator or triggers a loud alarm.

Different types of event processing

Event processing refers to the various automation techniques and approaches used to handle events within an event-driven system. Here are some of the different types of event processing:

  1. Stream processing: Processing and analyzing data as it flows through a system. Events can be processed as they occur, providing real-time insights and allowing the system to respond quickly to changes. For example, a stock trading system can use stream processing to analyze stock prices and execute trades in real time.

  2. Complex event processing (CEP): Analyzing multiple events to identify patterns and correlations between them. CEP allows the system to detect complex events and respond accordingly, such as triggering an alarm when multiple sensors detect abnormal conditions. For example, an airport security system analyzing multiple security cameras and other sensors can use CEP to identify patterns of behavior that may indicate a security threat and alert security personnel.

  3. Rule-based processing: Using predefined rules to determine how events should be processed. If an event meets certain criteria, a specific action is triggered. For example, a fraud detection system can use rule-based processing to analyze e-commerce transaction data and trigger alerts for transactions that meet certain criteria.

  4. Time-based processing: Processing events based on their time of occurrence. Events that occur within a specific time frame can be grouped and processed. For example, an energy management system that analyzes power consumption data from multiple sources to optimize energy usage can use time-based processing to group data into time periods and analyze usage patterns to identify potential energy savings.

  5. Batch processing: Processing a large volume of events at once rather than processing them in real time. Batch processing is useful for analyzing historical data or performing resource-intensive operations. For example, a financial reporting system that generates reports on a daily or weekly basis can use batch processing to process large volumes of financial data and generate reports more efficiently.

  6. Pattern matching: Identifying patterns within a stream of events. This can be useful for detecting anomalies or identifying trends within a system. For example, an online advertising system that analyzes user behavior to display targeted ads can use pattern matching to analyze user data and identify patterns of behavior indicating interest in specific products or services.

Developers can use one or more of these to provide a flexible and scalable approach to handling events. The choice of event processing technique will depend on the specific requirements and goals of the system.

Other important terms

Here are some other terms that will come up in conversations about EDA.

  1. Event handler: A function or method executed in response to a specific event.

  2. Publisher-subscriber (pub/sub) model: A messaging pattern in which a publisher component sends messages (events) to a set of subscriber components that are interested in receiving those events.

  3. Event stream: A sequence of events that occur over time.

  4. Event processing language (EPL): A programming language used for processing events in real time. It provides constructs for filtering, aggregating, and transforming events.

  5. Event processing network (EPN): A graphical representation of an event processing system, which shows how events flow through the system and how different components process them.

  6. Business activity monitoring (BAM): A tool used to monitor and analyze business processes in real time.

How to integrate EDA into your development workflow

Integrating EDA into an existing development workflow requires careful planning and execution. Here are some steps that a developer can take to integrate it successfully:

  1. Evaluate the existing architecture and identify areas where EDA can improve system flexibility, scalability, and responsiveness. The most critical use cases often include real-time data analysis, real-time processing of user actions, and integration with external systems.

  2. Identify the appropriate tools and frameworks to support EDA, such as event processing engines, event brokers, and messaging middleware. These tools can manage event streams, perform event processing, and facilitate communication between ecosystem components.

  3. Define the event schema and metadata, which specify the structure and format of the events used in the system. This is necessary to ensure that events can be processed appropriately and interpreted by all system components.

  4. Design and implement event handlers, which are responsible for processing events and triggering appropriate actions or processes. Event handlers can be implemented as standalone components or integrated into existing software systems.

  5. Test thoroughly to ensure everything works correctly. This involves testing the event handlers, the event schema, and the overall system behavior.

  6. Monitor the system's performance and optimize it as necessary. This may involve analyzing event data to identify bottlenecks or other issues and making adjustments to improve system performance.

Integrating EDA into an existing development workflow can pose several challenges, such as ensuring compatibility with existing software systems, ensuring the security and privacy of event data, and managing event streams at scale. However, the most important thing developers must remember is to ensure the system remains flexible and adaptable.

EDA is all about responding to events as they occur, which means that the system needs to handle a wide range of events and react to them quickly.

To achieve this level of flexibility, developers must:

  • Design event schemas and handlers to be modular and loosely coupled: Each system component should be able to function independently and respond to events without relying on other components.

  • Focus on making event schemas extensible: They should be able to add new events to the system as needed without disrupting existing components.

Using EDA to scale, flexibly

By leveraging EDA, developers can design more scalable, flexible, and responsive software. Developers who follow best practices and stay up-to-date on the latest EDA tools and frameworks can successfully integrate EDA into their development workflow and create high-performing, modern applications.
