How to Build a ReactJS Collaborative Text Editor with CRDTs

Real-time collaboration is expected these days. It is a common feature in most industries. Collaboration tools such as Atlassian, Trello, and of course, Google Docs have grown in popularity. All of these apps need real-time connectivity to enable collaboration. Let's start with the most challenging of them all! Google Docs! We can create our own live, online, collaborative text editor! Yes! You heard it right. Here's where PubNub API comes to the rescue!

Try it out live: https://stephenlb.github.io/pubnub-lexical-yjs-websocket/

Also, you can skip ahead and visit the GitHub repository: https://github.com/stephenlb/pubnub-lexical-yjs-websocket

In this guide, we will walk through building a live, real-time collaborative text editor using CRDTs, YJS, and a ReactJS plugin called Lexical from Meta. Combining these technologies allows us to recreate Google Docs. The entire process will work within a React environment, though this can be ported to other frameworks.

Getting Started with React and CRDT Dependencies

The first thing to do is set up a new React project. Then, we need to add the necessary dependencies, which include "lexical", "y-websocket", "react", and "react-dom". Here are the list of dependencies for your package.json file

"@lexical/react": "^0.14.2",

"lexical": "^0.14.2",

"react": "^18.2.0",

"react-dom": "^18.2.0",

"y-websocket": "^2.0.2"

1. And now we can run npm install to download the dependencies.

2. And start the local dev server, I tend to use the vite command to for this.

Setting Up Your ReactJS Text Editor

Now that our project is ready, we can code our collaborative text editor. Remember, our main goal is to create a platform where multiple users can work together, simultaneously. To kick things off, we've to import necessary Lexical components. These components, specifically the plugins, the composer, and YJS (our CRDT), facilitate real-time collaborative editing.

Next we need to set the configuration for he editor, where the Document ID or Namespace becomes essential in maintaining the document's integrity. This is the ID that will be used to transmit CRDT events, like the keystrokes on a keyboard, and any edits to the document such as bold styling. Make sure you set the namespace to the document ID. Each namespace will hold the document state.

Styling Your Editor and Adding Lexical Features

To add a personal touch, modify the theme and furnish user details. If you fancy specific text formats, Lexical settings has got you covered. It allows you to have a toolbar that presents different text formatting options. What's impressive about Lexical's editor text is its options and features. There's a lot to the editor, and you can pick and chose your favorite text editor style and plugin features: Lexical Plugins. The plugin that may be the most interesting is the OnChangePlugin plugin, which lets you run code to export the document from it's most recent state.

Integrating PubNub Configuration

The next step is to bring PubNub into the picture. To get your PubNub API keys, visit up https://admin.pubnub.com/ and log in. Use the Demo App Sandbox API Keys and add them to your pubnubConfig as shown above.

Collaborative Setup and Extras

Once PubNub is in place, it's time to set up the collaborative features. Decide on a cursor color and a username to showcase your user's needs.

You now have your own collaborative text editor in the mold of Google Docs. It combines the best of CRDTs, YJS, Lexical, React and PubNub! Build the app with tsc && vite build && mv dist/icons dist/assets/. Publish your app on GitHub pages or another hosting provider. Share the link and get started with online collaborative editing 🚀🎉

By leveraging CRDTs and the robust PubNub API, you can also explore creating other real-time applications. Not only it will meet your custom needs but will also put you in the driving seat of your own collaboration tool. Happy coding!

It seems that collaborative text editors with PubNub, CRDTs, Yjs, and Lexical plugin will be the future of real-time collaboration. So why wait, let's create the future today!

CRDTs and PubNub

Awesome! You've just built your very own Google Docs-like live collaborative text editor using CRDTs, Lexical by Meta, Yjs, and most importantly, PubNub. This is indeed how collaborative tools work, offering a communal space for work and promoting interactive collaboration among teams, irrespective of geographical boundaries.

With PubNub APIs, the possibilities of creating real-time applications like this are endless. Many popular collaborative tools in use today, such as Google Docs and Notion, utilize similar types of technology to provide their real-time collaboration features.

Out of all the technologies we've used, however, CRDTs truly stand out for their ability to handle conflict resolution with ease, ensuring consistency of collaborative work. When combined with the power of Lexical by Meta and real-time capabilities from PubNub, CRDTs form the backbone of this fascinating project.

Now, if you're interested in scaling this project into a fully fledged product or want to dig deeper into conflict resolution in real-time applications, I recommend you check out more detailed materials on CRDTs. You can also explore PubNub’s extensive documentation and other useful materials.

Keeping up-to-date with current technological advancements is key to staying relevant. Be sure to constantly learn, explore, experiment and most importantly, collaborate.

PubNub, CRDTs, and Lexical by Meta, we explored creating our own version of Google Docs. This is not only immensely satisfying as a software engineer but also a compelling example of the power of these technologies.

So, what are you waiting for? Give it a try and let me know how your experience of creating your own collaborative text editor goes! Feel free to reach out if you have any questions or stumble upon any issues. Happy coding!
